Vintage Decapped Ceramic Hybrid IC Gold-Plated Leads Exposed Die Collectible

Vintage ceramic hybrid integrated circuit with gold-plated leads and the package opened to expose the internal hybrid circuitry, semiconductor die, passive components, conductive traces, and bond connections. This device is being offered as a collectible semiconductor specimen, display piece, educational example, or microscopy subject.

Lifecycle: OBSOLETE

HISTORICAL BACKGROUND:
Ceramic hybrid microcircuits were used extensively in specialized industrial, military, aerospace, instrumentation, communications, and high-reliability electronic equipment. Unlike conventional single-die integrated circuits, hybrid assemblies could combine semiconductor dies, resistors, capacitors, and other components on a common substrate inside a ceramic package.

Gold plating and gold bonding were commonly used in high-reliability electronic assemblies because of gold's corrosion resistance and dependable electrical connection properties. Exposed examples such as this provide a direct view of an older method of microelectronic construction that has significant technical and collector interest.

The exact manufacturer, original part number, and equipment application of this device have not been verified.
