Right-Angle micro BNC Male to micro BNC Male Short RF Coaxial Pigtail Jumper Cable
$9.99
Short right-angle micro BNC male to micro BNC male RF coaxial jumper cable from surplus RF inventory. This cable has a right-angle BNC male connector on each end, with visible BNC bayonet-lock coupling hardware and male center contacts. It is useful for tight-space RF connections, test equipment, signal generators, counters, oscilloscopes, spectrum analyzers, radio bench work, antenna tuners, SDR projects, and custom coaxial assemblies.
Historical Note:
BNC coaxial connectors became a standard connection style for laboratory instruments, communications equipment, broadcast systems, and RF test gear because the bayonet-lock coupling allows quick cable changes while maintaining a shielded coaxial connection. Right-angle BNC jumpers are especially useful where straight connectors would place stress on a cable or interfere with nearby equipment.
Origin Tracker
Bench Stock
Pulled from RF Boneyard bench/service stock for practical repair and restoration use.
Pipeline quantities are informational and may change after arrival, inspection, sorting, testing, or donor teardown.
Compatible Radios / Boards
Suitable for equipment using BNC female mating connectors where a short right-angle BNC male-to-male coaxial jumper is needed. Common uses include RF test equipment, oscilloscopes, signal generators, counters, spectrum analyzers, ham radio projects, CB radio bench work, SDR equipment, antenna test fixtures, and custom RF assemblies.
Buyer must verify cable length, connector fit, impedance, frequency range, power level, cable condition, and electrical requirements before use. Not a universal replacement cable.
RF Boneyard Bench Notes
Tester Lead Mapping:
Not applicable; coaxial RF jumper cable assembly.
Bench Measurements:
Connector Type: BNC male to BNC male coaxial jumper cable
Connector Configuration: Right-angle BNC male connector on both ends
Connector Coupling: BNC bayonet-lock coupling
Center Contacts: Male center pins visible
Cable Style: Short coaxial jumper cable
Manufacturer: Unknown
Cable Marking: Partial marking visible; exact cable type not confirmed
Exact Cable Length: Not measured
Impedance: Not verified
Frequency Range: Not verified
VSWR: Not verified
Power Rating: Not verified
Insertion Loss: Not verified
Continuity Test: Not performed
Center Conductor End-to-End Test: Not performed
Shield End-to-End Test: Not performed
Center-to-Shield Isolation Test: Not performed
Bench Evaluation:
PASS - Random physical inspection completed.
PASS - Right-angle BNC male connectors are present on both ends.
PASS - BNC bayonet-lock coupling hardware and male center contacts are visible.
PASS - Cable assembly is physically intact as photographed.
PASS - Buyer must verify electrical continuity, cable condition, impedance, frequency range, and suitability before installation.
